UPnP |
Transcoding, proxying UPnP Server. DLNA device compatible |
|
Other Inputs |
NAS |
|
Analogue Outputs |
DIN, RCA |
|
Line Outputs Fixed (level) |
2.1V rms at 1kHz |
|
Output Impedance |
22Ω maximum |
|
Minimum Load Impedance |
10kΩ |
|
Frequency Response |
10Hz – 20kHz, +0.1/-0.5dB |
|
thd+n |
<0.1%, 10Hz -18kHz at full level |
|
Phase Response |
Linear phase, absolute phase correct |
|
Digital Outputs (type) |
S/PDIF, 75Ω BNC and TOSLINK |
|
Other Outputs |
Ethernet, UPnP |
|
Power Supply |
XPS, 555PS |
|
Other |
DAC, Hi-Line, Power-Line |
|
Infra Red |
RC5. 1 x handset included |
|
Remote Input |
3.5mm jack on rear (RC5) |
|
RS232 |
DE9 male |
|
TV Outputs |
1 x S-Video, 1 x Composite, 1 x 15 way D VGA, RCA |
|
Ethernet |
1 x rear panel RJ45 |
|
USB |
1 x front panel, 4 x rear panel |
|
Other |
iPhone/iTouch, VGA, 1 x PS2 keyboard and 1 x PS2 mouse |
|
CD Formats |
Red Book |
|
Disc Compatibility |
CD, CD-R, CD-RW |
|
Audio Formats Supported |
WAV, AIFF, FLAC, Apple Lossless, OGG Vorbis, AAC, WMA, MP3 |
|
Sample Rates |
44.1kHz, 48kHz, 88.2kHz, 96kHz and 192kHz native. Other rates converted to 44.1kHz |
|
Bit Depths |
16bit, 24bit, 32bit fixed, 32bit float |
|
TV Monitor |
4:3 and 16:9 customisable TV interface. IR handset and USB touchscreen compatible |
|
Front Panel |
Touch sensitive colour user interface. Sychronised TV interface |
|
Web Interface |
PC and MAC internet browser compatible Adobe Flash User interface |
|
AMX Creston |
Intstaller customisable reference apps available |
|
Handheld |
User interface for iPhone and iTouch devices, downloadable from App Store |
|
USB |
Scan and play from FAT and NTFS formatted memory sticks |
|
Network Shares |
Scan and play from music stored on a network share |
|
Network Storage |
Rip to external network storage for expanded music storage |
|
NaimNet |
6 user streams to NaimNet and NetStreams systems |
|
CD Metadata |
AMG online, FreeDB online and local database |
|
Mains Supply |
100-120V, 220-240V; 50 or 60Hz |
|
Certifications |
Streamnet enabled, DigiFi |
|
Licenses |
MP3, aac, AMG |
|
Dimensions |
87 x 432 x 314mm (H x W x D) |
|
Weight |
10.8 kg |
|
Notes |
Windows Media is a trademark of Microsoft Corporation. UPnP is a trademark of the UPnP forum. iPod and Mac are trademarks of Apple Inc, registered in the U.S. and other countries. Naim's HDX is powered by the DigiFi platform; leading edge software technol |
|
Front |
Brushed and black anodised |
|
Case |
Black powder coated |
