Technical data

Output voltage at 1000 Hz, 5cm/sec.

4 mV

Channel balance at 1 kHz

2 dB

Channel separation at 1 kHz

22 dB

Channel separation at 15 kHz

15 dB

Frequency range at - 3dB

20-25.000 Hz

Frequency response

20-20.000 Hz ± 2 dB

Tracking ability at 315Hz at recommended tracking force *)

65 µm

Compliance, dynamic, lateral

20 µm/mN

Stylus type

Elliptical

Stylus tip radius

r/R 8/18 µm

Tracking force range

1,5-2,0 g (15-20 mN)

Tracking force, recommended

1,75 g (17,5 mN)

Tracking angle

20°

Internal impedance, DC resistance

750 Ohm

Internal inductance

450 mH

Recommended load resistance

47 kOhm

Recommended load capacitance

200-600 pF

Cartridge colour, body/stylus

Black/Black

Cartridge weight

5 g

Replacement stylus unit

Stylus 5 E

*) Typical value
