ORTOFON MC 唱頭_01
ORTOFON MC SAMBA 唱頭
產品型號 :
ORTOFON MC SAMBA
市場售價 :
NT$
13500
.元
網路特價 :
NT$13500.元
購買數量：
(單位︰件)
貨物狀況 :
正常供貨
商品特色
商品規格
Technical data
Output voltage at 1000 Hz, 5cm/sec.
0,3 mV
Channel balance at 1 kHz
< 1 dB
Channel separation at 1 kHz
> 25 dB
Channel separation at 15 kHz
> 15 dB
Frequency range at - 3dB
20-30.000 Hz
Tracking ability at 315Hz at recommended tracking force *)
> 70 µm
Compliance, dynamic, lateral
14 µm/mN
Stylus type
Nude elliptical
Stylus tip radius
r/R 8/18 µm
Tracking force range
1,3-1,8 g (13-18 mN)
Tracking force, recommended
1,5 g (15 mN)
Tracking angle
20°
Internal impedance, DC resistance
6 Ohm
Recommended load impedance
> 10 Ohm
Cartridge body material
Noryl
Cartridge colour
Yellow transparent
Cartridge weight
7 g
*) Typical value
