Frequency Response |
20Hz − 20kHz, +0 / −0.25dB |
|
S/N Rate |
Headphone: LOW / HI: -103dB(Volume50% Maximum output / A-weighted)
Headphone Balance: -110dB(Volume50％ Maximum output / A-weighted)
Speaker(8 Ω): -103dB(Input 2Vrms / Output 10W) |
|
THD |
Headphone: LOW / HI: 0.06% (Input 1Vrms / Output 0dBu)
Headphone Balance: 0.009% (Input 1Vrms / Output +3dBu)
Speaker(8 Ω): 0.03%(Input 2Vrms / Output 10W) |
|
Output |
Headphone: LOW: 1.15W × 2(32 Ω)/ HI: 0.25W x 2 (32 Ω)
Headphone Balance: 4.7W × 2(32 Ω)
Speaker: 13W × 2(8 Ω), 18W× 2(4 Ω) |
|
Impedance |
Headphone: 16 Ω - 2k Ω/Speaker/ 4 Ω - 8 Ω |
|
Gain |
HI/LOW switchable |
|
Input Terminal |
Balance 1(XLR), Unbalance 1 (RCA) |
Headphone Output
(Impedance) |
Balance Type XLR 1 (0Ω, #2 Hot, #3 Cold)
6.3mm Jack 2 (10Ω and 120Ω) |
|
Speaker Output |
Balance 1 |
|
Power consumption |
Standby: 14W/ Headphone: 23W/ Speaker: 50W |
|
Power |
AC 100V/ 50,60 Hz |
|
Dimensions/Weight |
218(W) x 354(D) x 58(H) mm/3.2kg |
